The 200W Spektrum™ S1200 Smart G2 AC Charger provides easy charging for all modelers, especially using Smart batteries — with Auto Charge simplicity, one-connection balancing, IC3® or IC5® output ports for adapter-free convenience, and more.
Features
- Delivers 200W power for charging
- Charges AND balances Smart G2 batteries with one simple IC3® or IC5® connection — no separate balance lead needed
- Auto Charge recognizes Smart battery charging parameters and begins safe, accurate charging automatically when connected
- Charges virtually any RC battery (use Smart batteries to benefit from all charger features)
- Smart software tracks and stores numerous Smart battery data
- Includes IC3® and IC5® charging output ports — no separate adapters required to charge different Spektrum™ Smart batteries
- An on-screen clock counts down remaining charge time until your Smart battery is fully charged and ready to use
- Updated user interface features fresh, intuitive menus, icons and navigation tools, plus non-slip, easy-to-use buttons
- USB input and output ports are included for updating firmware and charging secondary devices
- ON/OFF switch eliminates the need to plug in and unplug the power cord for on/off control
- Detachable power cord makes transporting more convenient
- Includes an efficient, low-noise cooling fan
- Compact size and sleek, sturdy case fits well on a workbench and in pit or field bags
- Handy rubber grips on case make it easier to plug in and remove batteries
IC3® and IC5® connectors are backwards compatible with EC3™ and EC5™ connectors
Specifications
- Product Length: 5.7' (145 mm)
- Product Width: 5.7' (145 mm)
- Product Height: 4.1' (104 mm)
- Thermal Protection: Yes
- Discharge: 0.1 - 1.5A (10W Max)
- Maximum Charge Rate: 15 or More Amps
- Reverse Polarity Protection: Yes
- Integrated Balancing: Yes - Internal Balancer & Internal Adapter
- Maximum Continuous Discharge Current: 10W
- Software Updates: Yes
- Technology: Smart
- Display: 2.4' 320 x 240 IPS LCD
- Hard Case: Yes
- Input Voltage: 100-240V AC
- Part Type: Electronics
- Power (watts): 200 - 399W
- Amp Meter: Yes
- Application: RC model battery charger
- Output Connector: IC3, IC5
- Peak Detection: Yes
- Product Weight: 2.2lbs (1015g)
- Short Circuit Protection: Yes
- Battery Type: Smart, Non Smart
- PC Connectivity: Yes
- Programmable: Yes
- Safety Timer: Yes
- Normal/Standard Charge Current: 0.1 - 15.0A, adjustable in 0.1A increments
- Voltage Meter: Yes
- Battery Balance Connector: JST-XH
- Battery Temperature Monitoring: Yes
- Charge Protection Circuitry: Yes
- Number of Cells: 1 - 6S Li-Ion/LiPo/LiFe, 1 - 16S NiCd/NiMH, 1 - 12S Pb
- Number of Output Ports: 1
- Power Source: AC
- Selectable Charge Rate: Yes
- Over Current Protection: Yes
- USB Power out: Yes
Includes
- 1pcs S1200 Smart G2 AC Charger
- 1pcs Power Cord
- 1pcs Product Manual
