The Gens Ace IMARS D300 is a smart, dual-channel AC/DC RC battery charger designed for high performance and convenience. Compatible with both G-Tech smart batteries and standard LiPo, LiFe, LiHV, and NiMH chemistries, this advanced charger offers automated detection for G-Tech packs and flexible manual control for all others. With a robust output of up to 700W on DC input and up to 300W on AC, the D300 handles high-capacity charging with ease. Equipped with a clear 2.4-inch IPS LCD display, the charger offers a user-friendly interface and seven charging modes—including balance, storage, discharge, external discharge, and digital power supply. Its compact size and lightweight design make it ideal for field use, while the built-in safety systems protect against overcharging, short circuits, and overcurrent events.
Features
- Dual channel AC/DC smart balance charging with independent outputs
- Supports Gens Ace G-Tech smart batteries with automatic detection
- Compatible with standard LiPo, LiFe, LiHV (1–6S) and NiMH (1–16S) batteries
- Up to 16A charge current per channel
- Maximum power: 300W (AC) / 700W (DC)
- 2.4-inch IPS wide-view LCD screen for clear monitoring
- Multiple operation modes: Charge, Discharge, Balance, Storage, External Discharge, SyncCharging, Power Supply
- Compact and lightweight design for portability
- Advanced heat dissipation and flame-retardant construction (UL94-V0 grade)
- USB port for 5V / 2.4A device charging
Specifications
- Input Voltage: AC 100–240V / DC 7–30V
- Output Voltage: 1–30V DC
- Charge Current: 0.1–16A x2
- Discharge Current: 0.1–3A x2
- Max Charging Power: 300W (AC) / 350W x2 (DC)
- Max Discharging Power: 15W x2
- Cell Support: 1–6S LiPo/LiFe/LiHV, 1–16S NiMH
- USB Output: 5V / 2.4A
- Display: 2.4' IPS LCD
- Dimensions: 145 x 76 x 62 mm
- Weight: 530g
Includes
- 1 x IMARS D300 Dual Channel AC/DC Smart Charger
- 1 x AC Power Input Cable
- 1 x XT60 to T Adapter
- 1 x XT60 to EC5 Adapter
- 1 x XT60 to EC3 Adapter
Important Notes
- Ensure compatibility with your battery type before use
- Use only in well-ventilated areas with proper supervision
